| MOQ: | 1 |
| Standard Packaging: | brown box |
| Delivery Period: | 3-5days |
| Payment Method: | T/T |
| Supply Capacity: | 1000000 per week |
Alarm mode positioning
Historical trajectory
Blind spot reporting
Electronic
fence
Power outage alarm
Light sensitive anti
| No. | Item | Specifications | Remarks |
|---|---|---|---|
| 1 | Operating Voltage | DC 3V | |
| 2 | Operating Current | 45~75mA@3V | |
| 3 | Standby Current | Less than 15uA | |
| 4 | Dimensions | L77mm*W41mm*H27mm | |
| 5 | Positioning Method | Satellite Positioning (GPS+BD) + Base Station Positioning + WIFI Positioning | |
| 6 | Positioning Error | GPS Positioning Error <30m (Reference data, positioning error is related to terrain, time, and other factors) Base Station Positioning Error depends on base station density WIFI Positioning <30m |
Data from company lab tests |
| 7 | Communication Network | 4G | Frequency Bands: B1/B3/B5/B8/B3/B38/B39/B40/B41 |
| 8 | Communication Method | UDP | |
| 10 | Operating Temperature Range | -25℃ ~ +75℃ | |
| 11 | Storage Temperature Range | -40℃ ~ +85℃ | |
| 12 | Net Weight | 100g | |
| 13 | Battery Life | Can operate continuously for 3 years with new batteries | 2 CR123A batteries (3000mAh) |
| Feature Details | Feature Description |
|---|---|
| Alarm Mode | Can set up to 4 wake-up times per day. Automatically wakes up at the set time, sends location data, and then goes to sleep. |
| Timing Mode | Periodically sends location data according to the set time interval. |
| Week Mode | Sets a specific time and selects one or several days of the week to send location data and then goes to sleep. |
| Base Station + GPS + WIFI Positioning | Automatically switches to base station positioning when WIFI and GPS are unavailable. |
| Serial Port Settings | Can set IP, port, APN, device number, alarm mode, timing mode, and week mode. |
| SMS Settings | Can set IP, port, APN, device number, alarm mode, timing mode, and week mode via SMS. |
| SMS Query | Returns current terminal parameters via SMS. |
| Anti-Tamper Alarm | Detects changes from dark to light and sends an alarm to the platform (can be controlled, default is on). |
| Anti-Fake Base Station | Terminal detects fake base stations and refuses to connect, preventing detection. |
Check the device's appearance and ensure all accessories are included.
Open the device and insert the SIM card into the slot. Avoid excessive force to prevent damage. Do not insert or remove the SIM card while the device is powered on. Ensure the SIM card has internet access.
A. Waterproof: Choose a location that is not prone to water ingress to keep the terminal dry. Avoid air conditioning vents to prevent condensation inside the terminal, which can affect its lifespan.
B. Vibration Resistance: Do not install the terminal in areas with prolonged strong vibrations.
C. Interference Prevention: Keep the terminal away from in-car audio and communication devices to avoid conduction and radiation interference.
|
|
